Canyon Ridge

Canyon Ridge® Louver

5/5

Insulated garage doors with composite louver overlays

Add charm to your home with plantation shutter style Canyon Ridge® Louver garage doors. This versatile design perfectly complements coastal or colonial homes, and is a standout piece on traditional exteriors or modern farmhouses. Get the look of authentic louver doors with the convenience of upward operation.

Overview

Clopay Canyon Ridge® Louver garage doors are inspired by plantation shutters. These doors are constructed with steel for strength and durability, and molded composite overlays for a truly authentic look. These doors feature:

  • 5-layer steel base with faux wood cladding and overlay.
  • Faux wood-look composite cladding and overlay materials are molded from actual wood pieces to reproduce the natural texture and intricate grain patterns of the species they emulate.
  • Colors include: Walnut, Dark, Medium, Slate, Black, White, and Primed.
  • 2″ Intellicore®  polyurethane insulation with a thermal break. R-Values up to 20.4.
  • WINDCODE® door reinforcement product available for high wind load applications.

Environmental Assurance

Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:

  • California SB 1013
  • Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
  • Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
  • New Jersey A-5583/S-3919 – Greenhouse Gas Bill

Design Options

Customize your Clopay® Canyon Ridge® Louver garage door to make it your own. Designs, colors and windows create the perfect look. Choose Mahogany Louver cladding and pair it with either Mahogany or Clear Cypress overlays. If you are in search of more color options, our ColorBlast® program allows you to select from hundreds of Sherwin-Williams® color options or mix the perfect custom color.

DOOR DESIGNS

SERIES 4

SERIES 5

TOP SECTIONS

COMPOSITE CLADDING/BASE MATERIALS

COMPOSITE OVERLAY MATERIALS

Composite Cladding and Overlay material options may be mixed and matched.

COLORS

Steel surfaces have woodgrain texture

*Available on select models. For more information regarding color availability.

Black and White available only in Mahogany.
Two-tone option available: One color for the base layer (Steel and Composite Cladding) and one color for the top layer (Composite Overlay).

Custom color available through ColorBlast® program.

HARDWARE DESIGNS

HANDLES

HINGES

Construction

Clopay® Canyon Ridge® Louver garage doors are built five layers strong. The faux wood-look composite overlay and cladding surfaces are low maintenance, durable and won’t rot, warp or crack.

Warmer. Quieter. Stronger.
Garage doors featuring Intellicore® insulation technology represent the ultimate smart choice for homeowners. Clopay’s Intellicore® is a proprietary polyurethane foam that is injected into a garage door, expanding to fill the entire structure. The result is a door with incredible strength, energy efficiency and durability.

  • Door sample shown in Slate Finish.
  • Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
  • High performance nylon ball bearing rollers help ensure smooth, long-lasting, quiet operation.
  • Heavy-duty 14 gauge steel hinges and brackets for smooth and worry-free operation.
  • Window grilles are removable for easy cleaning.
  • Safe-T-Bracket® – Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
  • Product complies with 2015 IECC air infiltration requirement of 0.40 cfm/ft2 or less (IECC, Section C402.5.2)
